SIEMENS - Contactor AC-3 5,5kW/400V, 1M, 230V AC, 50/60 Hz, 3P, S00, schroefklemmen
1 3RT10171AP01

De afbeelding is louter informatief en niet bindend
ARTIKELREFERENTIE
Referentie leverancier
3RT10171AP01
Commerciële referentie leverancier
3RT1017-1AP01
EAN
4011209272842
Cebeo ID
278811
Categorie
PC3
LINKS
VOORRAAD
OMSCHRIJVING
Contactor AC-3 5,5kW/400V, 1M, 230V AC, 50/60 Hz, 3P, S00, schroefklemmen
- Nom. stuurspanning Us bij AC 50HZ: 230V - 230V
- Nom. stuurspanning Us bij AC 60HZ: 230V - 230V
- Nom. stuurspanning Us bij DC: 0V - 0V
- Type spanning voor bekrachtiging: AC
- Nom. bedrijfsstroom Ie bij AC-1, 400 V: 22A
- Nom. bedrijfsstroom Ie bij AC-3, 400 V: 12A
- Nom. vermogen bij AC-3, 400 V: 5.5kW
- Nom. bedrijfsstroom Ie bij AC-4, 400 V: 8.5A
- Nom. bedrijfsvermogen bij AC-4, 400 V: 4kW
- Modulaire uitvoering (DIN-rail): Ja
- Aantal hulpcontacten als maakcontact: 1
- Aantal hulpcontacten als verbreekcontact: 0
- Aansluitwijze hoofdstroomcircuit: Schroefaansluiting
- Aantal hoofdcontacten als verbreekcontact: 0
- Aantal hoofdcontacten als maakcontact: 3
VERPAKKING
Eenheidsverpakking:
1
Bestelhoeveelheid
1
